OOB Module
[Preliminary]
The Out-of-Band (OOB) management of OOB Board is a complete solution that provides remote device management services.
The Out-of-Band (OOB) management of OOB Board is a complete solution that provides remote device management services.
Conquer the final challenge of your edge AI projects: seamless deployment and scalable management. The Out-of-Band (OOB) management of OOB Board is a complete solution that provides remote device management services.
In the event of an edge system malfunction and subsequent shutdown, the OOB function can be utilized to power the system back on and verify whether the device has resumed normal operations.The OOB Board offers customers a customizable cloud-based device management portal for easily controlling all edge devices remotely.
Model | OOB Module | ||||||
---|---|---|---|---|---|---|---|
Applicable product | |||||||
System | Nuvoton NUC980 | ||||||
External I/O | •1 x RJ45 10/100Mb (LED indicator) •1 x Micro SIM slot for 4G module* | ||||||
Internal I/O | •1 x 15pin wafer for PWB、RST、5V、3V3、 Sys Debug UART、I2C、auto- link UART、 Power detecting pin、 GPIO •1 x 10pin wafer for NCSI (supported by D115W & D135)** •1 x reset button •1 x DIP switch for function setting •1 x USB type-C for MCU update •1 x 2pin wafer for SSD recovery (TBD)** | •1 x 15pin wafer for PWB、RST •1 x reset button •1 x DIP switch for function setting •1 x USB type-C for MCU update •1 x 2pin wafer for SSD recovery (TBD)***
| |||||
Expansion | •1 x M.2 Key. B 3042 (only USB2.0) for 4G module* | NA | |||||
Power Input | 5V power | 3V3 power | |||||
Environment | •Operating temperature -40°C ~ 85°C (TBD, The actual situation depends on the box PC spec. ) •Storage temperature -40°C ~ 85°C | ||||||
Mechanical | 55 x 56.2mm | ||||||
Package | •OOB Board •Cable •Screws |
* We will support this feature upon customer request.
**The 10pin wafer on D131/D131L/D315 doesn't support NCSI.
*** The 2-pin wafer is for Apacer's SSD recovery function.
**** All specifications are subject to change without prior notice.
